General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Door Color | Stainless Steel |
| Handle Color | Stainless Steel |
| Trim Color | Stainless Steel |
| Total Capacity (cu. ft.) | 7.4 |
| Number of Oven(s) | Double |
| Fuel Type | Dual Fuel (NG) |
| Door Panel Type | Glass |
| Burner Type | Sealed |
| Range Type | Freestanding |
| Number of Elements/Burners | 6 |
| Cooktop Surface Style | Burner Grate |
| Grate Material | Cast Iron |
| Oven Cleaning Method | Self Cleaning/Steam Clean |
| Total Number Of Oven Racks | 3 |
| Total Number Of Rack Positions | 5 |
| Oven Features | Adjustable Leg Height, Broiler in Oven, Keep Warm, LED Display, Oven Light, Proofing Mode, Pizza Cooking Mode, Oven Temperature Probe, Delay Bake/Start, Sabbath Mode |
| Cooktop Features | Continuous Grate, Digital Display, LP Convertible, Removable Grates, Griddle Included, Dishwasher Safe Grates, Control Lockout |
| Air Fry | No |
| Induction Cooking | No |
| Convection Cooking | Yes |
| Smart Compatible | No |
| Outdoor Approved | No |
| Downdraft Ventilation | No |
| Drawer Type | No Drawer |
| Appliance Fit Width (in.) | 48 |
| Width (in.) | 47.9375 |
| Height (in.) | 36 |
| Depth (in.) | 24.75 |
| Depth w/Door Open 90 Degrees (in.) | 45.3593 |
| Cut Out Depth (in.) | 25 |
| Cut Out Width (in.) | 48 |
| Cut Out Height (in.) | 36 |
| Product Weight (lbs.) | 291 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Commercial Use Approved | No |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Collection | 800 Series |
| Series | 800 Series |
| Voltage | 208/240 |
| Frequency | 60 |
| Amp | 40 |
Additional Dimensions |
| Overall oven interior dimensions (HxWxD) | main oven: 15.04" x 28.46" x 17.72" secondary oven: 17.80" x 10.75" x 16.54" |
| Usable oven interior dimensions (HxWxD) | main oven: 14.57" x 26.97" x 16.14" secondary oven: 13.94" x 9.33" x 14.76" |
| Adjustable range height | 34.8125" Min. - 36..8125" Max. |
| Oven cavity size | main oven: 5.4 cu.ft.; secondary oven: 2.0 cu.ft. |
| Plug type / Cord length | 1.5m with plug NEMA 14-50 |
| Plug type | US 4-prong |
| Cord length | 60" with plug |
| Gas type | Natural gas 14.9 mbar (USA) [7" WC] |
| Alternative gas type | LP 27.4 mbar (USA) [11" WC] |
| Bake / broil element watts | 1,700 / 1,700 W (main), 750 / 1,400 (Aux) |
| Convection element watts | 2x 1,500 W (Main), 1,550 W (Aux) |
| Total cooktop (NG / LP) BTU | 73,000 / 71,000 |
| Power of front left burner (NG / LP) BTU | 20,000 / 18,000 |
| Power of back left burner (NG / LP) BTU | 5,000 (OptiSim) / 5,000 |
| Power of back center burner (NG / LP) BTU | 12,000 / 12,000 |
| Power of front center burner (NG / LP) BTU | 12,000 / 12,000 |
| Power of back right burner (NG / LP) BTU | 12,000 / 12,000 |
| Power of front right burner (NG / LP) BTU | 12,000 / 12,000 |
| Electric griddle | 1,600 W |
